automobile driving belt fatigue test bench is used to test the v belt and poly v-belt’s fatigue life. (fatigue life is indicated to the normal operation hours when the v belt comes to the end of terms)

applicable standardsgb 11545-2008

type introduction

qc- vpl-3a------------ automobile driving belt fatigue test bench

depending on the different specimen take two, three, four-wheel test. correctly test case to determine the driving wheel, the rear wheel, reverse bending wheel position at a predetermined speed, the provisions of the load, when the specimen appears damaged or slip rate of 4%, respectively, stop the trial.

during the test, when broken down to check each case or slip down to reach 4%, must press the "stop check button" on the control panel, then open the box check specimen

click the "data setting button" to enter data setting screen (shown below), the system default displays the last information on a test, you can modify may be re-entered on this basis. double-click the "test date" dialog box, you can automatically fill test date, when selecting the "conveyor belt of the type", the system will automatically fill in the "load weight", "preset speed," "preset power" and other data, as reference test, after checking if wrong, please correct manually. when selecting the "test method" fill in "after the sample length", double "preprocessing shift" dialog box, you can automatically calculate the active and center distance driven wheels, check the calculation is correct, according to this distance adjustment initiative, driven pulley location. tensioned wheel for loading test required weight. click "save data" and exit back to the main program. the new reform program and to add the "last data button", the program default parameters set out last time, click the button, the last time the test data and test to the first few times out automatically, and then click the "save data "after the exit back to the main program, we can continue to cook after a trial at the pre-test.
