一.overview

this test stand is used to test oil filter without filter base inlet and outlet check valves.

二.model

machine oil filter inlet and outlet check valve test stand

三.equipment overview

3.1 equipment size：1300x850x3300，weight：400kg

3.2 equipment power supply：three-phase five-wire system ac380v，3kw

四.required for testing

4.1 test medium：sae 5w30或sae 5w40machine oilor the test medium purchased by your company，minimum volume：18l

4.2 power：three-phase five-wire system ac380v，3kw以上or more

4.3 dry cleaning gas source：8bar supply pressure not less than 8bar

四.：applicable standard

iso 4548-9:2008

五.：test item

spin-on oil filter without filter base

inlet and outlet check valve leakage (measured by cylinder)

inlet and outlet check valve opening pressure (calculated by standard pass height)

六.technical parameters：

6.1、：±2℃temperature control range: room temperature -90 °c, control accuracy: ± 2 °c

6.2、temperature test range: 0-100 °c, accuracy: ± 0.5 °c;

6.3、high and low test range: 0mm-2000mm, accuracy: ± 0.5mm;

6.4、 main tank volume: stainless steel 20l

6.5、 lifting tank capacity: stainless steel 5l

6.6、maximum specimen size: maximum specimen height 175mm

6.7、supply voltage: 380v/50hz

6.8、 rated power of equipment: 3kw

七.product function introduction and features。

7.1, the test bench adopts sheet metal spray, all pipelines and pipe joints are made of anti-rust material.

7.2. use a motor reducer to drive the lift tank to lift manually. the outer pointer and pull-wire displacement sensor control the lift height.

7.3. the main tank is automatically heated to the set temperature. the lift tank is heated with external cladding.

7.4, the use of rotary joints, in the premise of ensuring the seal can make the filter reverse 180 °.

7.5, using plc + touch screen control system to operate, simple and convenient operation, lift height, tank temperature display on the touch screen, test data can be output via usb, the device itself without storage.

7.6. use pneumatic ball valves to switch pipelines, gear oil pumps to circulate, and the lower part to receive oil trays.

7.7, overall protection: high oil temperature alarm, motor over-current protection, low pressure alarm, warning labels.
