关键字导读： xf-mjb fire extinguisher alternating pressure testing machine
描述：used for testing the pressure of the fire extinguisheralternating performance
[testing items]used for testing the pressure of the fire extinguisheralternating performance
[applicable standards]
gb 4351.1-2005 portablefire extinguishers—part 1:performance and construction
ga 86-2009 simplified fire extinguishers
gb8109-2005 wheeled fire extinguishers
[features]
this system adoptsmicrocomputer testing process automatic control, automatic data acquisition andgenerate reports, etc. the test workbench made of stainless steel wire drawingboard visible explosion-proof box cover, safe and beautiful, durable, highquality. convenient cart fire extinguishers and other fire extinguishersinstalled in a test bench, convenient and quick way of connection, reliableconnection, convenient operation. it is the ideal choice of the domestic atpresent to carry out such testing project.
[technical parameters]
•test range and accuracy: pressure range 0 ~ 24mpa,
•accuracy: 0.5% f.s, resolution: 0.1mpa
•pressure source of water: more than 15l / min
•test medium temperature range: water
•pressure control station quantity: pressure four stations
•specimen size: portable fire extinguishers, wheeled fireextinguishers, simplified fire extinguishers
•power configuration: ac380v, power:15kw, three-phasefive-wire system
• weight: 0.5 tons
