关键字导读： the sg plastic pipe pressure measuring instrument
描述：forthe national standard the following subjects in parts, including the detectionof bursting pressure pipes and fittings.
[testing items]
forthe national standard the following subjects in parts, including the detectionof bursting pressure pipes and fittings.
[applicable standards]
iso9080, iso1167
gb/t10002.1-2006 unplasticizedpoly(vinyl chloride)(pvc-u) pipes for water supply
gb/t10002.2-2003 fittingsmade of unplasticized poly(vinyl chloride)(pvc-u) for water supply
gb/t10002.3-96valvesmade of unplasticized poly(vinyl chloride)(pvc-u)for water supply
gb6111-2003 thermoplastics pipes forthe conveyance of fluids-resistance to internal pressure-test method
gb/t15560-1995 determinationof shrinkage for injection moulding thermoplastics
gb/t18252-2000plasticspiping and ducting systems--determination of the long-term hydrostatic strengthof thermoplastics materials in pipe form by extrapolation
gb/t27726-2011 thermoplasticsvalves—pressure test methods and requirements
gb/t18742.1-2002 polypropylenepiping systems for hot and cold water installation--part 1:general
gb/t18742.2-2002 polypropylenepiping systems for hot and cold water installation--part 2:pipes
gb/t18742.3-2002polypropylene piping systems for hot and cold water installation--part 3:fittings
[features]
microcomputer system automatic implementation: unified control pressure, branch, branchpressure, pressure, pressure, pressure, instantaneous segregation, rupturetime, the burst pressure peak value shows the archive, the key technologies oftemperature control, etc.
microcomputerwindow each interface can be printed, experimental results and automaticallygenerate and print the report.
aftera power outage, the system to store the current results, after the call, themicrocomputer automatic start, and
fromthe breakpoint continued to experiment, without the artificial monitoring
.[technical parameters]
type:sg1-110 type sg3-110 type sg6-110 type
pressure test range: 0.3 ~14 mpa accuracy: 0.5
constant pressure control of time: 1min~5000h arbitrary set
blasting test time: 20s~100s in any setting
the accuracy of the time: 0.1%
temperature range: ambient temperature ~95℃accuracy:1.5℃
controlcabinet length * width * height (mm): 1000 x 600 x 1600 1000 x 670 x 1600 1150 x 750 x 1780
waterbath box length * width * height (mm): 600 x 540 x 910 1050 x 600 x 1130 1150 x 750 x 1780
withpower ac 380v (three-phase five wire system): the power : 7 kw ,12 kw ,7 kw
weight:300kg 500kg 650kg
control mode: touch screen computer
